BMS Battery Protection Board 1S 3.7V 3A li-ion 18650 AA AAA Lipo Li-ion Lithium Battery BMS Charger Protection Module Board Circuit

Model: HX-2S-D01

• Size: approx.41*16*3.5mm
• Over voltage range: 4.25-4.35v±0.05v
• Over discharge voltage range: 2.5-3.0v±0.05v
• Limited current: 15A
• Upper working current: 8A
• Quiescent current: less than 10uA
• Operating temperature: -40 – +50℃
• Storage conditions: -40 – +80℃
• Resistance: less than 30 mohm (<0.03ohm)
• Short circuit protection: protection, charge recovery
• Useful life: more than 50000 hours
• Main function: over charging protection, over discharge protection,short circuit protection,over current protection function.
